xWith a top speed of 120 km/h, much higher than many 12 Inch Hub Motors on the market, the 12 Inch Brushless Gearless Hub Motor directly drives the wheels to rotate, eliminating the need for driveshafts, transmissions or differentials. This design simplifies the vehicle structure, reduces mechanical losses, and increases energy efficiency for a variety of scenarios, including urban commuting, recreational riding, custom modifications, and light off-roading.
| Model Type | 12 Inch Brushless Gearless Hub Motor |
| Design | Brushless Gearless |
| Voltage | 36V/48V/60V/72V |
| Rated Power | 1500W/2500W/3500W/5000W |
| Speed | 40-120km/h |
| Maximum Torque |
55N.m |
| Magnet Poles |
20 |
| Tire model | 12*2.125 |
Brushless Design: Brushless DC motor (BLDC) is used to replace mechanical brushes by electronic commutation, completely eliminating the physical contact between the brush blades and the commutator, thus avoiding mechanical wear. Brushless motors are more durable than brushed motors and are suitable for long time high load operation.
Gearless Construction: The gearless design reduces mechanical friction and meshing noise due to its lack of a gear system, reducing maintenance requirements. Gearless motors run quieter and are suitable for urban environments.
Certifications: High safety margins are achieved through strict manufacturing standards to ensure stability at high speeds. Manufacturers have ISO9001, CE, CCC and UL certifications, among others.
Key benefits of 12 Inch skateboard hub motors include:
Simplified Vehicle Structure: Eliminates the need for traditional transmissions, driveshafts, differentials and other components, resulting in a more compact vehicle structure.
Higher Transmission Efficiency: The motor directly drives the wheels, reducing losses in the power transmission process and theoretically improving energy utilization.
Better Maneuverability: The ability to control each wheel independently allows for more precise torque distribution and more flexible vehicle dynamics, such as four-wheel independent drive.
Design Flexibility: Provides greater freedom in vehicle design, making it easier to realize various drive forms (e.g., front, rear, four-wheel drive).
| Environment | Suitability | Legal considerations | Safety considerations |
| City commuting | Not suitable, speeding may be illegal | Speed limit 20-30 km/h, registration required | High safety risk, avoidance recommended |
| Recreational riding | Very suitable, high speed zones allowed | No public restrictions, use in dedicated areas | Protective gear required, track supervision |
| Custom modifications | Very suitable, high flexibility | No restrictions, suitable for DIY projects | Need to ensure frame and design match performance |
| Light off-road | Partially suitable, flat terrain required | Permit may be required, depending on area | Complex terrain, need to be aware of stability |
Potential Considerations:
Power Requirements: Reaching speeds of 120 km/h requires a significant amount of power (wattage) and a high-voltage battery system.
Controller Compatibility: Motors need to be paired with compatible motor controllers that can handle the voltage and current requirements.
Safety: E-bikes and scooters traveling at 120 km/h can pose a safety hazard and may be illegal in many areas. The frame, brakes, tires, and overall design of the e-bike must be strong enough to withstand such speeds.
Regulations: It is important to be aware of local e-bike/scooter speed limits and regulations.
Customized Range
xLunyee Mobility specializes in developing, designing, customizing, manufacturing and marketing products such as hub motors, drive axles and wheelchair motors to suit different applications. Hub motors are customized to include size, power, voltage, speed, torque and control system tuning to meet specific operational needs. Our customization capabilities include
- Tire Size:
- The choice of tire size can have a significant impact on the performance of an electric motor. Customizable options range from compact 4-inch wheels for light-duty applications to 16-inch or larger wheels for high-load agricultural and industrial vehicles.
- Performance:
- Performance customization includes factors such as torque output, speed and energy efficiency. High-torque motors are ideal for heavy-duty applications, while high-speed motors are suitable for performance-based solutions such as electric scooters or e-bikes.
- Rated Power:
- Power options vary by application needs, from low-power 250W motors for electric unicycles to high-power 3000W motors for high-performance vehicles. The amount of power directly affects load capacity, acceleration and durability, so it can be customized to meet specific operational needs.
- Voltage:
- Voltage customization ranges from 24V for light-duty applications to 72V for high-power systems, with higher voltages contributing to increased efficiency and power output for applications requiring extended range and enhanced performance.
